The NAD C569 is a high-performance CD player at a realistic, offering cutting-edge technologies in a slimline format it will perform way above its price point and competes with far more exotic and expensive players.
The NAD C 569 CD Player is designed for music lovers who value the experience of choosing an album and hearing their CD collection with greater depth, nuance, and presence. A proven tray-loading CD mechanism and NXP-based servo system support consistent playback, while carefully arranged internal circuitry helps keep unwanted noise away from sensitive audio signals
We are not able to send NAD products outside of UK
The NAD C569 is a high-performance CD player at a realistic, offering cutting-edge technologies in a slimline format it will perform way above its price point and competes with far more exotic and expensive players.
The NAD C 569 CD Player is designed for music lovers who value the experience of choosing an album and hearing their CD collection with greater depth, nuance, and presence. A proven tray-loading CD mechanism and NXP-based servo system support consistent playback, while carefully arranged internal circuitry helps keep unwanted noise away from sensitive audio signals. NAD Dynamic Digital Headroom (DDH), LMG’s QRONO d2a technology, and an ESS Sabre DAC further refine digital playback, preserving timing, dynamics, and the natural character of each recording. With intuitive operation and flexible analogue and digital outputs, the C 569 brings renewed enjoyment to familiar albums and the experience of listening from beginning to end.
KEY FEATURES
Proven tray-loading CD mechanism with NXP-based servo system for consistent, reliable playback
Carefully arranged internal circuitry designed to minimise unwanted noise and interference
NAD Dynamic Digital Headroom (DDH) to reduce distortion from inter-sample clipping
LMG’s QRONO d2a technology for improved timing and natural musical detail
ESS ES9039Q2M Sabre DAC for high-performance digital-to-analogue conversion
Refined stereo analogue output stage with carefully selected audio components
Clear front-panel display with CD-Text support for album and track information
Intuitive front-panel controls and included remote control for convenient operation
Analogue outputs for direct connection to an amplifier or preamplifier
Digital outputs for connection to an external DAC or compatible digital component
General Specifications
Output level
Line Out: 2.2 ±0.2V Digital Audio Out – Coaxial: 0.5 – 0.8 Vp-p 75 ohms
Frequency response
0 dB, 20 Hz – 20 kHz (±0.5 dB)
Total harmonic distortion
≤0.006% (1kHz, LPF 20kHz)
Signal/Noise ratio
≥110 dB (1 kHz, A-weighted LPF 20 kHz Play)
Channel balance
0.5 dB (0 dB 1 kHz)
Channel separation
≥110 dB
De-emphasis
-3.73 to -5.33 dB (0 dB 1kHz, 5 kHz) -8.04 to -10.04 dB (0 dB 1 kHz, 16 kHz)
Linearity
-3 ±0.1 dB (0 dB 1 kHz at -3 dB) -6 ±0.2 dB (0 dB 1 kHz at -6 dB) -10 ±0.25 dB (0 dB 1 kHz at -10 dB) -20 ±0.25 dB (0dB 1 kHz at -20 dB) -60 ±0.5 dB (0dB 1 kHz at -60 dB)
Standby power
<0.5W
Idle power
≤ 20 W
Weight & Dimensions
Gross dimensions (W x H x D)
435 x 83 x 294 mm
17 1/4 x 3 3/8 x 11 5/8 inches
Net weight
4.2 kg (9.2 lbs)
Shipping weight
6.2 kg (13.7 lbs)
Brand
NAD
NAD Electronics at Audiologica
